The GoodWe GW12K-ET-20 G2 Series is a three-phase high voltage battery hybrid inverter, suitable for residential and commercial applications. This inverter combines excellent performance with flexible configuration and extensive backup capabilities.

Key Features:

✔ Maximum efficiency of 98.2%

✔ 3 MPPTs and 3 DC inputs for design freedom

✔ Backup power up to 12,000 VA (18,000 VA peak for 60 sec)

✔ Support for Li-Ion batteries with 150–720 V

✔ Communication: RS485, CAN, WiFi, LAN, Bluetooth

Technical specifications:

• Nominal power: 12,000 W

• Max. AC output current: 17.4 A

• Max. PV input: 19,200 W

• Max. battery charge/discharge current: 40 A

• Battery to AC efficiency: 97.5%

• Dimensions: 496 × 460 × 221 mm

• Weight: 25 kg

• Protection degree: IP66

Datasheet download
